RODEO TILT-IN-SPACE WHEELCHAIR (Convaid)
|
|||
Convaid Product Catalog 2010 |
|||
- Description
- Features
- Request a Quote
- Send to a Friend
The Rodeo tilt-in-space chair offers 10-45° of adjustable tilt and 90-105° of adjustable seat-to-back angle. Key features include extensive positioning options; a height-adjustable push handle; height-adjustable armrests; firm lateral supports; removable, machine-washable fabric with side panels; and an optional storage tray located under the seat for storing medical necessities and auxiliary equipment, such as a ventilator.
It's lighter than the Safari, just as compact-folding, and folds with all positioning options in place. Its patented design provides maximum comfort and durability.
Available in two models: Basic, with many features available, and a crash-tested Transit model, designed for use aboard a bus or van.
It's lighter than the Safari, just as compact-folding, and folds with all positioning options in place. Its patented design provides maximum comfort and durability.
Available in two models: Basic, with many features available, and a crash-tested Transit model, designed for use aboard a bus or van.
- Elevating one piece footplate
- Crash-tested transit models available sizes 12 , 14 and 16
- Optional firm lateral supports & medical necessity tray
- Ultra-lightweight Tilt-In-Space
- Adjustable tilt
Features
- Compact folding
- Optional medical necessities tray under chair
- Comprehensive positioning
- 10-45 degree adjustable tilt
- 90-105 degree seat-to-back angle
- Height adjustable armrests
- Crash-tested transit model available
- Optional medical necessities tray under chair
- Removable fabric
- Firm lateral supports
- Side panels
RD 12 Specifications
- Overall width open: 20" (51 cm)
- Overall height open (upright position, measured from handle): 40.5" (103 cm)
- Shoulder strap height: 18.5-23.5" (47-59.7 cm)
- Weight of chair (Standard model): 28 lbs (10.5 kg)
- Weight capacity (Regular model): 75 lbs (34 kg)
- Weight capacity (Transit model): 66 lbs (30 kg)
- Overall length open (upright position): 34" (86 cm)
- Folded dimensions (l x w x h): 34" x 20" x 17" (86 x 51 x 43 cm)
- Headrest extension: 8" (20 cm)
- Seat back height: 21.5" (55 cm)
- Seat to footrest (min/max): 8-13" (20-33 cm)
- Seat width: 12" (30.5 cm)
- Seat depth: 11-14" (28-35.5 cm)
- Seat to back angle: 90° - 105°
- Tilt adjustment (from vertical): 10° - 45°
- Footplate angle - adjustable: 15°
- Seat to floor: 20" (51 cm)
RD 14 Specifications
- Overall width open: 22" (56 cm)
- Overall height open (upright position, measured from handle): 44" (112 cm)
- Shoulder strap height: 18.5-24" (47-61 cm)
- Weight of chair (Standard model): 29 lbs (12 kg)
- Weight capacity (Regular model): 100 lbs (45.5 kg)
- Weight capacity (Transit model): 100 lbs (45.5 kg)
- Overall length open (upright position): 40" (102 cm)
- Folded dimensions (l x w x h): 35" x 22" x 17" (89 x 56 x 43 cm)
- Headrest extension: 8" (20 cm)
- Seat back height: 24" (61 cm)
- Seat to footrest (min/max): 9.75-15" (25-38 cm)
- Seat width: 14" (35.5 cm)
- Seat depth: 13-16" (33-41 cm)
- Seat to back angle: 90° - 105°
- Tilt adjustment (from vertical): 10° - 45°
- Footplate angle - adjustable: 15°
- Seat to floor: 21" (53 cm)
RD 16 Specifications
- Overall width open: 24.5" (62 cm)
- Overall height open (upright position, measured from handle): 45" (114 cm)
- Shoulder strap height: 20-25.5" (50.8-64.8 cm)
- Weight of chair (Standard model): 35 lbs (14 kg)
- Weight capacity (Regular model): 170 lbs (77 kg)
- Weight capacity (Transit model): 170 lbs (77 kg)
- Overall length open (upright position): 43" (109 cm)
- Folded dimensions (l x w x h): 34.5" x 24" x 17" (87.5 x 62 x 43 cm)
- Headrest extension: 8" (20 cm)
- Seat back height: 24" (61 cm)
- Seat to footrest (min/max): 12-17.5" (30-44 cm)
- Seat width: 16" (40.5 cm)
- Seat depth: 15-18" (38-46 cm)
- Seat to back angle: 90° - 105°
- Tilt adjustment (from vertical): 10° - 45°
- Footplate angle - adjustable: 15°
- Seat to floor: 23" (58 cm)
